The Teledyne FLIR T1020-28 HD Thermal Imaging Camera delivers expert-level infrared imaging with unmatched clarity and precision. Built on decades of thermal innovation, this high-performance tool incorporates a 1024 x 768 detector, MSX and UltraMax technologies, and an integrated viewfinder to ensure the sharpest thermal detail and measurement accuracy. Whether assessing mechanical systems, inspecting electrical panels, or conducting R&D, the T1020-28 meets the demands of the most rigorous professionals.

Equipped with the OSX Precision HDIR optical system, this camera provides an ultra-clear thermal view across varying distances. Advanced features like 1-Touch Level/Span, intuitive GUI navigation, and full-frame radiometric video capture make operation seamless. With the benefit of Teledyne FLIR Tools software included, users can quickly analyze data and generate insightful reports.

What's Included:

• Teledyne FLIR T1020-28 HD Thermal Imaging Camera
• 28° Precision HDIR Lens
• Built-in Viewfinder
• Teledyne FLIR Tools Software
• Battery and Charger
• Carrying Case
• Calibration Certificate
• USB Cable and Video Output Accessories

Features

High-Resolution Thermal Imaging
Features a 1024 x 768 detector with UltraMax enhancement, delivering up to 3.1 MP thermal resolution for crisp image detail.

Enhanced Measurement Accuracy
UltraMax technology improves spot-size ratio, making temperature readings more precise, even on small targets.

Integrated MSX Technology
Multi-Spectral Dynamic Imaging (MSX) overlays visual edge detail onto thermal imagery for improved scene context.

Wide Object Temperature Range
Measures temperatures from -40°C to 2000°C, suitable for a broad spectrum of electrical, mechanical, and industrial applications.

Customizable PIP and Alarms
Includes resizable Picture-in-Picture and user-configurable alarms for above/below thresholds and insulation/moisture detection.

Full Radiometric Video Recording
Capture high-speed, full-resolution radiometric video for advanced diagnostics and reporting.

Built-In Viewfinder
800 x 480-pixel viewfinder enhances usability in bright conditions or detailed inspection tasks.

Advanced Analysis Tools
Up to 10 spotmeters and 5 5 area tools provide detailed temperature analysis with min/max/avg values.

GPS and Compass Tagging
Automatic geolocation for image logging and documentation in the field.

User-Friendly Interface
Intuitive touchscreen interface and dynamic focus control streamline workflows and reduce inspection time.

What's Included

Included with Your Purchase:

• Teledyne FLIR T1020-28 HD Thermal Imaging Camera
• 28° Precision HDIR Lens
• Built-in Viewfinder
• Teledyne FLIR Tools Software
• Battery and Charger
• Carrying Case
• Calibration Certificate
• USB Cable and Video Output Accessories

Specifications

• IR Resolution: 1024 x 768 (786,432 pixels)
• UltraMax Resolution: 3.14 MP
• Thermal Sensitivity/NETD: < 20 mK @ 30°C
• Field of View: 28° x 21° (36 mm lens)
• Viewfinder Resolution: 800 x 480 pixels
• Picture-in-Picture: Resizable and movable
• IR Time-Lapse: 15 seconds to 24 hours
• Temperature Ranges: -40°C to 150°C, 0°C to 650°C, 300°C to 2000°C
• Accuracy: ±1°C or ±1% at 25°C for 5°C to 150°C range
• Alarms: Above, below, interval, moisture, insulation
• Alarm Output: Audible and visible triggers
• GPS & Compass: Automatic image tagging
• METERLiNK: Multiple sensor reading integration
• Spotmeters: Up to 10
• Measurement Areas: 5 boxes and 5 circles with max/min/avg
• Display: Responsive GUI with 1-Touch Level/Span
• Radiometric Video: Full-frame and full-resolution capability

FAQ

Q: What is UltraMax and how does it benefit thermal imaging?
A: UltraMax captures multiple images to enhance resolution and accuracy, resulting in clearer images and smaller spot sizes for more precise measurements.

Q: Can this camera be used in bright outdoor conditions?
A: Yes, the integrated high-resolution viewfinder enables effective use even in bright lighting environments.

Q: What software is included with the T1020-28?
A: It comes with Teledyne FLIR Tools software for thermal image analysis, video review, and professional reporting.

Q: Is the device suitable for high-temperature applications?
A: Yes, it measures up to 2000°C, making it ideal for industrial, power generation, and metallurgical tasks.

Q: Does the camera support radiometric video recording?
A: Yes, it captures full-frame radiometric video for in-depth post-capture analysis.

Resources

Documents:

• T1K Series Datasheet
• T1K Series Brochure
