General | |
| Lens Material | sapphire crystal |
|---|---|
| Bezel Material | stainless steel |
| Case material | fiber-reinforced polymer with metal rear cover |
| QuickFit™ watch band compatible | yes (26 mm) |
| Strap material | silicone |
| Physical size | 52 x 52 x 17.8 mm Fits wrists with the following circumference: |
| Color display | |
| Display Size | 1.4” (35.56 mm) diameter |
| Display resolution | 280 x 280 pixels |
| Display Type | sunlight-visible, transflective memory-in-pixel (MIP) |
| Weight | silicone band: 103.8 g |
| Dive (100 meters) | |
| Battery life | Smartwatch: Up to 16 days |
| Memory/History | 32 GB |
Clock Features | |
| Time/date | |
|---|---|
| GPS Time Sync | |
| Automatic daylight saving time | |
| Alarm clock | |
| Timer | |
| Stopwatch | |
| Sunrise/sunset times | |
Health Monitoring | |
| (constant, every second) | |
|---|---|
| yes (high and low) | |
| (24x7) | |
| yes (spot-check, and optional all-day acclimation and in sleep) | |
| yes (in app) | |
| yes (in Garmin Connect™) | |
| yes (in Garmin Connect™) | |
Sensors | |
| GPS | |
|---|---|
| GLONASS | |
| Galileo | |
| Garmin Elevate™ wrist heart rate monitor | |
| Barometric altimeter | |
| Compass | |
| Gyroscope | |
| Accelerometer | |
| Thermometer | |
| Depth sensor | |
| Pulse Ox Blood Oxygen Saturation Monitor | |
Daily Smart Features | |
| Connectivity | Bluetooth® Smart, ANT ®, Wi-Fi® |
|---|---|
| Connect IQ™ (downloadable watch faces, data fields, widgets and apps) | |
| Smart Notifications | |
| Text response/reject phone call with text (Android™ only) | |
| Calendar | |
| Weather | |
| Battery saver (customizable low power watch) | |
| Controls smartphone music | |
| Plays and controls watch music | |
| Music storage | up to 2,000 songs |
| Find My Phone | |
| Find My Watch | |
| VIRB® Remote | |
| Smartphone compatibility | iPhone®, Android™ |
| Pairs with Garmin Connect™ Mobile | |
| Garmin Pay™ | |
Safety and Tracking Features | |
| LiveTrack | |
|---|---|
| Group LiveTrack | |
| Live Event Sharing | |
| Incident Detection during select activities | |
| Assistance | |
Tactical Features | |
| Dual grid coordinates | |
|---|---|
Diving Features | |
| Dive activity maximum operating depth | 100 meters |
|---|---|
| Single-gas mode | |
| Multi-gas mode | |
| Gauge mode | |
| APNEA mode | |
| APNEA hunt mode | |
| Decompression model | Bühlmann ZHL-16c with gradient factors |
| Nitrox support | |
| Trimix support | |
| Closed Circuit Rebreather (CCR) | |
| Gas mixes | Air, Nitrox and Trimix, up to 100% O2; 1 bottom gas and up to 11 deco and/or backup gasses. |
| PO2 | Up to 2.0 with customizable deco PO2 setting |
| Auto start/end dive | |
| Custom end-dive timeout | yes (20s to 10 m) |
| Safety Stop | yes (customizable off/3min/5min) |
| Deep Stops | yes (using custom gradient factors) |
| Customizable conservatism | yes (low/medium/high or custom using gradient factors) |
| Dive ascent/descent rate indicator | |
| Automatic altitude adjustment | |
| No fly time | |
| Dive planner | yes (basic NDL multi-gas deco planner) |
| Tides | |
| Backlight | yes (configurable time and intensity; auto-on at depth) |
| Automatically saves dive entry and exit locations | |
| Custom dive data screens | |
| Sync dive log to Garmin Dive™ Mobile app | |
| Alerts & alarms | Audible and vibration alarms for ascent rate, PO2, CNS/OTU, NDL, deco, gas switching. Customizable (up to 40) audible and/or vibration per dive mode, based on depth or time |
| 3-axis dive compass | yes (with adjustable heading, quick change to 90R, 90L and reciprocal). Indicates degrees and direction back to set heading |
| Missed Deco Lockout | yes (can be disabled prior to dive with user acknowledgement) |
| Residual Tissue Loading Reset | yes (on the surface with user acknowledgement) |
| Surface diver status widget | yes (surface interval, N2/HE loading, CNS, OTU and tissue compartment status) |
Boating Features | |
| Available Boating Profiles | Boating |
|---|---|
| Built-in barometer and tide tables | |
